чаша iVario Pro
Отображаются все 2 результата
Поз. Артикул Описание Кол-во
1 87.01.605S Kit pan with pressure 1
1.1 10.02.267P Gasket 3x10mm 3.2
2 20.01.653S Plug for pan valve with gasket 1
3 20.00.993P Gasket for plug pan valve 1
4 20.01.587S Sheath for pan valve 1
5 10.00.675P O-ring f. pan valve 17.3 x 2.4 1
7 20.03.450S Pan valve cable pan left 1
8 20.03.600P O-ring 9.8×1.5 1
9 40.06.857S Thermocouple pan left 1
10 87.00.339 Thermocouple for heating element 1
11 87.00.674 Conversion kit heating element 2287W 230V 12
12 40.04.370P Safety temperature limiter heating element 12
13 40.04.501P Safety temperature limiter 130° 1
14 40.02.337P Safety temperature limiter 215°C 1
15 20.01.508P Spacer for safety temperature limiter 2
16 20.01.518P Graphit plate for safety temperature limiter 2
17 20.03.024P Stop for pan 2
21 20.03.658S Front reinforcement of pan headband 1
22 20.03.661S Transverse pan reinforcement 1
23 20.03.505P Pan reinforcement 1
24 87.01.564S Lid locking assembly 1
25 20.03.341S Master-slave link assembly 1
26 40.06.880P Master-slave connection cable 1
27 20.03.696P Connecting link ISO06B-1 Form E 1
28 20.03.705P Gasket for lid locking assembly 2
30 40.06.458P Magnetic contact 1
31 20.03.667S Magnetic contact support 1
40 16.03.844P Front panel for pan 1
41 10.01.808P Hex socket countersunk head screw M5x16 2
42 16.03.842P Lower panel for pan 1
43 10.01.808P Hex socket countersunk head screw M5x16 4
44 16.03.841P Back panel for pan 1
45 10.01.808P Hex socket countersunk head screw M5x16 2
46 16.03.556P Side panel right of pan 1
48 16.03.372P Side panel left of pan 1
49 16.03.706P Sealing device for left panel 1
50 20.03.254P Mounting piece for pan panel 1
51 20.03.474P Pan front insulation 1
52 20.03.466P V-profile gasket 3.2
100 40.05.946P Power harness heating element 1
101 40.05.932P Thermocouple harness 1
